DTA series Thermal silicon pad with adhesive

Home > Thermal gap pad > DTA series Thermal silicon pad with adhesive

[Return Home] [Go Back]

Product Name:
DTA series Thermal silicon pad with adhesive
Model No.:
DTA150

Product Description

DTA series Thermal silicon pad with adhesive

The DTA series is adhesive thermal conductive silicon pad, mainly for the thermal conductivity between the heating device and the heat sink or the product outer covings without fastening devices.

Features & benefits:
●Ultra-stickiness
●Without fastening devices
●Electrically isolating
● Meet with the environmental requirements of ROHS and UL

Typical applications:
●LED light
●Power conversion equipment
●Between the semiconductor or magnetic body and heat sink
●HID ballast
●Household appliances

Physical properties:

Test item	Test method	Unit	DTA150 Test value
Color	Visual		Grey
Thickness	ASTM D374	Mm	0.5 to 13
Specific Gravity	ASTM D792	g/cc	1.8±0.1
Hardness	ASTM D2240	Shore C	20 to 50
Tensile Strength	ASTM D412	kg/cm²	8
Tensile Strength	ASTM D412	Pa	5.88*10⁹
Continuous Use Temp	EN 344	℃	-40 to +220
Volume Resistivity	ASTM D257	Ω-CM	1.0*10¹¹
Breakdown Voltage	ASTM D149	KV/mm	4
Flame Rating	UL-94		V-0
Conductivity	ASTM D5470	w/m-k	1.5

Configurations available: 200mm*400mm, 300mm*300mm, customized size available.
